MAINTENANCE FREE WITH ACID PACK
| Battery Model | Voltage(V) | Capacity (Ah) | Length ±2 (mm) | Width ±2 (mm) | Height ±2 (mm) | Net Weight (kg) | Acid Weight (L) |
|---|---|---|---|---|---|---|---|
| YTX3L-BS | 12 | 3 | 98 | 57 | 109 | 0.87 | 0.28 |
| YTX4L-BS | 12 | 3 | 113 | 69 | 85 | 1.11 | 0.28 |
| YTX5L-BS | 12 | 4 | 113 | 69 | 104 | 1.36 | 0.4 |
| YTX5AL-BS | 12 | 5 | 120 | 60 | 125 | 1.44 | 0.44 |
| YTX6.5L-BS | 12 | 5.5 | 139 | 67 | 98 | 1.53 | 0.51 |
| YTX7L-BS | 12 | 6 | 113 | 69 | 130 | 1.79 | 0.49 |
| YTX7A-BS | 12 | 6 | 150 | 87 | 93 | 1.76 | 0.59 |
| YTX7A-BS | 12 | 7 | 150 | 87 | 93 | 1.93 | 0.59 |
| YTX7DL-BS | 12 | 7 | 148 | 60 | 129 | 1.76 | 0.59 |
| YTX7E-BS | 12 | 7 | 134 | 75 | 121 | 1.93 | 0.74 |
| YTX9-BS YTX9L-BS | 12 | 8 | 150 | 87 | 103 | 2.1 | 0.7 |
| YTX9A-BS YTX9AL-BS | 12 | 8 | 135 | 75 | 137 | 2.13 | 0.74 |
| YTX12-BS | 12 | 10 | 150 | 87 | 130 | 2.78 | 0.98 |
| YTX14-BS | 12 | 12 | 150 | 87 | 145 | 3.18 | 0.98 |
| YTX16-BS | 12 | 14 | 150 | 87 | 162 | 3.56 | 1.1 |
| YTX20-BS | 12 | 18 | 175 | 87 | 155 | 4.3 | 1.35 |
| YTX20L-BS | 12 | 18 | 175 | 87 | 155 | 4.3 | 1.35 |
| YTX30L-BS | 12 | 28 | 167 | 127 | 174 | 6.8 | 2.7 |
